Please be advised that this product is only available for sale and after-sales support in certain regions. For further details, kindly consult with your local sales representative. Thank you for your understanding.
Wide applicable range
Applicable to tubing sizes from OD1/4″ to OD1″, covering common-used tubing diameters in the biopharmaceutical industry
High compatibility
Suitable for 2 major TPE tubings on the market: C-Flex® 374 and AdvantaFlex TM, The sealing process for tubing from other brands is customizable.
Comfortable operation
The tubing can be operated at a length as short as 17 cm, facilitating the operation.
Fast and efficient
The sealing process can be completed within 3–4.5 min based on the tubing size and TPE material. Two cooling modes are available: high-speed and medium-speed.
Lightweight and portable
Lightweight design, with the entire machine weighing only 4kg.
Flexible
The device can be hung vertically or placed horizontally according to the actual use conditions; the screen can rotate and the display is excellent in either position.
Economical and practical
Sterile disconnection can be easily achieved with one device, no accessory needed when switching between different tubing diameters.
Easy-to-use
Operators are guided in tubing to be sealed and a step-by-step process displayed on the screen, and can easily track and monitor every step of the sealing process.
User-friendly HMI
5-inch touch screen, displaying sealing process in real-time.
Remarkable sealing effect
Sealing can be achieved for empty tubings, tubings with liquid, and tubings with liquid under pressurized conditions; the seal width is up to 20 mm, with a clear cutting guide line to ensure accurate disconnection.
Reliable data
Five-level permissions are available, with more detailed audit trail and function classification.
Highly stable
The device has built-in aging test program; each unit undergoes a 48-hour continuous sealing test before leaving the factory to ensure stable operation.
| Power supply | 220 V/50 Hz |
| Power | 300 W |
| Equipment dimensions | 390 mm * 157 mm * 142 mm |
| Net weight | 4 KG |
| Heat sealing duration | 3 - 4.5 min |
| Cooling mode | Air cooling |
| Heat sealing conditions | 5 ~ 40℃, 50% ~ 80% RH |
| Protection level | IP22 |
| Item | Product code |
| BioHub® Sealer Ⅱ | BLKSEALER02 |
| IOQ Validation Service | IOQ-SEAL-01 |
