Detailed Introduction
Chromatography resin based on an improved agarose-based matrix with ultra-high binding capacity and high resolution. With both high binding capacity and high resolution, presenting excellent cost performance. With organic solvent resistance and good chemical stability.
Compared with traditional ion exchange chromatography media, MaXtar® Q/SP HR XL shows better performance:
The improved MaXtar® base frame has stronger rigidity, so it can achieve higher process flow rate and improve process efficiency under lower back pressure.
By upgrading the ligand coupling method, with dextran extension arms, the dynamic binding capacity of the chromatography medium is improved.
Finer particle size improves the resolution of the chromatographic medium.
| Product |
Inner diameter × Column bed (mm) |
Dynamic binding capacity |
Mean particle size (μm) | Max. back pressure (MPa) | Recommended flow velocity (mL/min) | Quantity | Product code | ||||||||
|
Chrom-Trap MaXtar® Q HR XL 1 mL |
7.7/25 | > 160 mg BSA/mL | 40 | 0.5 | 1 | 1 × 1 mL | 2014-1911 | ||||||||
|
Chrom-Screen MaXtar® Q HR XL 4.7 mL |
7.7/100 | > 160 mg BSA/mL | 40 | 0.5 | 1 – 4.7 | 1 × 4.7 mL | 2014-1912 | ||||||||
|
Chrom-Trap MaXtar® Q HR XL 5 mL |
16/25 | > 160 mg BSA/mL | 40 | 0.5 | 1 – 5 | 1 × 5 mL | 2014-1913 | ||||||||
|
Chrom-Trap MaXtar® SP HR XL 1 mL |
7.7/25 | > 160 mg ovalbumin/mL | 40 | 0.5 | 1 | 1 × 1 mL | 2011-1911 | ||||||||
|
Chrom-Screen MaXtar® SP HR XL 4.7 mL |
7.7/100 | > 160 mg ovalbumin/mL | 40 | 0.5 | 1 – 4.7 | 1 × 4.7 mL | 2011-1912 | ||||||||
|
Chrom-Trap MaXtar® SP HR XL 5 mL |
16/25 | > 160 mg ovalbumin/mL | 40 | 0.5 | 1 – 5 | 1 × 5 mL | 2011-1913 | ||||||||
|
Product |
Dynamic binding capacity |
Mean particle size (μm) |
Max. back pressure (MPa) |
Max. flow velocity (cm/h) |
Quantity | Product code | |||||||||
| MaXtar® Q HR XL | > 160 mg BSA/mL | 40 | 0.5 | 600 | 25 mL | 1014-1911 | |||||||||
| 100 mL | 1014-1912 | ||||||||||||||
| 500 mL | 1014-1913 | ||||||||||||||
| 1 L | 1014-1914 | ||||||||||||||
| 5 L | 1014-1915 | ||||||||||||||
| 10 L | 1014-1916 | ||||||||||||||
| 20 L | 1014-1917 | ||||||||||||||
| MaXtar® SP HR XL | > 160 mg ovalbumin/mL | 40 | 0.5 | 600 | 25 mL | 1011-1911 | |||||||||
| 100 mL | 1011-1912 | ||||||||||||||
| 500 mL | 1011-1913 | ||||||||||||||
| 1 L | 1011-1914 | ||||||||||||||
| 5 L | 1011-1915 | ||||||||||||||
| 10 L | 1011-1916 | ||||||||||||||
| 20 L | 1011-1917 | ||||||||||||||
